Playground Equipment Specifications
PLAYGROUND EQUIPMENT SPECIFICATIONS
Blue Imp playground equipment is built to last using superior materials and craftsmanship. All products meet or exceed the current CAN/CSA Z614, ASTM F1487 and CPSC standards.
Posts: in-line galvanized steel with triple layer protection for maximum strength and corrosion resistance; lifetime warranty.
Hardware: tamper-resistant stainless steel for durability and safety; lifetime warranty.
Components & Rails: in-line galvanized steel tubing with UV-resistant polyester powder coating.
Finish: high performance, solvent-free polyester powder coating for UV and humidity resistance as well as maximum colour and gloss retention in weather extremes.
Platforms, Stairs & Stepping Saucers: one-piece perforated steel plate with a heavy-duty vinyl coating for durability and resilience; 8mm (5/16”) perforations to minimize moisture and ice retention.
Stainless Steel Slides: bedway constructed of 1.65mm (16ga) stainless steel. Durable, vandal-resistant, static-free and 100% recyclable.
Plastic Slides: moulded from medium density, UV-inhibited, food-grade polyethylene resin. Double-walled with an average wall thickness of 8mm (5/16”) for strength and safety.
Plastic Panels: 19mm (3/4”) thick, high-density, UV-stabilized, food-grade extruded polyethylene sheet.
Rope/Net Components: 16mm (5/8″) dia., constructed of 6 high-strength strands of steel wire and synthetic fibers, thermo-fix bonded over a 3-strand fiber core to form durable yet flexible rope.
Rootz Wood-Look Slats: composite wood material with Solid Core technology for maximum durability and damage resistance.
PLAYGROUND FORMATS
- Robust round steel support posts, 89mm (3.5”) O.D.
- Clampless, tamper-resistant connection system with pre-drilled mounting holes for easy install
- Heavy-duty round steel support posts, 127mm (5”) O.D.
- Clampless, tamper-resistant connection system with pre-drilled mounting holes for easy install
- Well-suited for high-use applications
- Robust round steel support posts, 89mm (3.5”) O.D.
- Clampless, tamper-resistant
connection system - Contemporary deckless designs ideal for older children
